LED Flextra Quad 80W work ligh

The Quad work light series is something extra for those who value both function and appearance. Elegant appearance combined with the highest possible quality. Let it light up your surroundings while gilding your vehicle with an exclusive look. Choose between 3 different colors to choose from on the position light. You can also choose not to turn on the position light and use it as a normal work light. Thoroughly tested to work on work vehicles and trucks in the Nordic climate every day all year round. Light, function and form in total symbiosis.

Voltage: 12–48 V
Power: 80 W
Diods: OSRAM-P8 5 W x 16 pcs, RGB 0.1 W x 26 pcs
Beam: Flood
Theoretical Lumen: 9280 lm
Actual Lumen: 6146 lm
IP class: IP68/69K
Operation temperature: -40 °C–+60 °C
Dimensions (WxHxD): 114 x 112 x 74,8 mm
Height included bracket: 146,8 mm
Cable: 50 cm cable
Approvals: ECER10, R7, CISPR25-class 3

LED Flextra Quad 45W work / reverse ligh

The Quad work light series is something extra for those who value both function and appearance. Elegant appearance combined with the highest possible quality. Let it light up your surroundings while gilding your vehicle with an exclusive look. Choose between 3 different colors to choose from on the position light. You can also choose not to turn on the position light and use it as a normal work light. Thoroughly tested to work on work vehicles and trucks in the Nordic climate every day all year round. Light, function and form in total symbiosis.

Voltage: 12–48 V
Power: 45 W
Diods: OSRAM-P8 5 W x 9 pcs, RGB 0.1 W x 24 pcs
Beam: Flood
Theoretical Lumen: 5 220 lm
Actual Lumen: 4 032 lm
IP class: IP68/69K
Operation temperature: -40 °C–+60 °C
Dimensions (WxHxD): 102 x 100,8 x 62,5 mm
Height included bracket: 130,2 mm
Cable: 50 cm cable
Approvals: ECER10, R7, R23

Work light with wide beam type approved as reverse light. Housing in aluminum and lens in polycarbonate. Thermal protection of wrong connections and overvoltage. Bracket in stainless steel. Built in DT connector for easier mounting.

Technical data:
Voltage: 9–36 V
Diods: 24 x 1,5 W
Theoretical Lumen: 3650 lm
Actual Lumen: 2950–3150 lm
Power: 36 W
Dimensions WxHxD: 107 x 100 x 47 mm
Height incl bracket: 129 mm
Cable: Inbuilt DT04-2P included connection cable
IP-class: IP69K
Approved according to: EMC R10 class 4 and ECE R23

E-approved powerful LED driving light. Housing in aluminum with ABS reflector and lens in polycarbonate. Biuld in deutsch connector 3 pin. Connections cable 30 cm included. Position light built in.

Referens number: 45
Voltage: 9-36 V
Power: 40 W
Diods: 8x5 W OSRAM
Beam: Spot
Theoretical Lumen: 6700 lm
Actual Lumen: 6000-6250 lm
IP class: 69K
Operation temperature: -40°C - +60°C
Dimensions: Diam 190 mm Deep 132 mm
Height included bracket 233 mm
Cable: Built in deutsch DT04-3P
Approved according to R10 and R112

Auxiliary driving lights LED 9” with heating lens, 9-36V, R112,R7,R10, REF: 45

E-approved powerful driving light in LED. Heated lens for best performance. Housing in aluminum with ABS reflector and lens in polycarbonate. Vibration damped bracket included. Deutsch connector DT4 connection cable 50 cm included into the box. Parking light in two color, white and amber. 1 lux = 454 m.

The heating function will be activated automatically when the light is on and the green LED indicates that the heating function is working. When the temperature of the front cover reaches approx. 40℃, the heating function is turned off automatically.

Referens number: 45

Voltage: 9–36 V

Power: 150 W

Diods: 30 x 5 W Cree

Beam: Combo

Theoretical Lumen: 13 500 lm
Actual Lumen: 10 500 lm

IP class: IP68

Operation temperature: -40 °C – +60 °C

Dimensions: Diam 216 mm Deep 74,4 mm

Height included bracket 225 mm

Cable: Deutsch connector DT4 with 50 cm connection cable.

Approvals: ECE R112, R7, R10, CE

Combined work lighting and warning light in the same lamp. Aluminum housing for the best cooling and polycarbonate lens for extra good durability. Approved as a reversing light (ECE R23). Delivered complete with U-bracket, Deutsch connector DT4 and connection cable. Built-in frame included.

Voltage: 9–36 V

Power Worklight: 32 W

Power Warninglight: 12 W

Diods Worklight: 4 x 8 W

Diods Warninglight: 4 x 3 W

Beam: FLOOD

Theoretical Lumen: 3 200 lm
Actual Lumen: 2 700 lm

IP class: IP68

Operation temperature: -40° C – +60° C

Dimensions LxHxD : 164 x 41 x 61 mm

Cable: Deutschconnector DT4 with 50 cm connection cable.

Approvals: ECE R23, R65, R10, CE, EMC class 3

0

Technical data:
Reference number: 30
Voltage: 9–36 V
Diodes: 12 x 5 W Osram
Theoretical lumen: 5000 lm
Real lumen: 3500–3750 lm
Power consumption: 60 W
Dimensions (WxHxD): 345 x 38 x 65 mm
Cable length: 50 cm deutsch contact male + 50 cm deutsch contact female
IP Class: 68
Other: E-approved according to ECE-R10 and R112

LED ramp with reflector technology slim design. Only 550 mm width and 38 mm high. Reflector technology optimizes the light image and the design is stylish on modern vehicles. The reflector’s optics focus the light on areas where the normal lighting of the vehicle is insufficient. The light image is wide and flat just like the road, thereby minimizing light losses into the air as well as down the nearby roadway which, in wet asphalt, may provide dazzling reflections. For maximum durability, the lens is polycarbonate.

Manufacturer:	Flextra
Voltage [V]:	9 - 36
Power [W]:	250
Lumen [lm]:	18750
Diods:	50x5W
Position light:	Ne
Beam type:	Flood
Light type:	LED
Width [mm]:	1294
Height [mm]:	48.5
Depth [mm]:	86
IP class:	IP68
Cable:	1 m
EMC:	ECE R10
Driving light approval:	Ne
Unit weight:	5.690 kg

LED SLIM REFLECTOR BAR
LED ramp in slim design with reflector technology. The optics of the reflector concentrate the light in areas where the vehicle's normal lighting is not enough. The light pattern is wide and flat just like the road, thereby minimizing light losses into the air and down into the nearby roadway, which can otherwise cause blinding reflections on wet asphalt.
For maximum durability, the lens is made of polycarbonate. Universal mounts included. Perfect if you want to replace the extra lights with an easy-to-mount ramp.

Technical data:
Voltage: 9 – 36V
Diodes: 20x5W
Theoretical lumens: 9000 lm
Actual lumens: 6300 lm
Power consumption: 100W
Dimensions (wxhxd): 544x53x89mm
Cable length: 50 cm deutschkontakt male + 50 cm deutschkontakt female
IP class: 68
Other: E-approved according to ECE-R10. EMC shielded according to EN55015. 5878202 approved according to R112
Through PWM technology (Pulse Width Modulation), the LEDs are switched on and off with a frequency so high that the eye does not have time to register a flicker. This technology is used both to be able to drive the diodes harder with a lower heat development and to function as a power-regulating electronic protection when the lamp risks getting too hot. This increases the lamp's performance and extends its lifespan.

Item Type Range (m@1Lux)

5878202 20x5W SPOT 387m


Is approved as additional light according to regulation ECE R112
